LRV8 P3Ta Pulley

LRV8 P3Ta Pulley

LRV8 P3Ta Pulley



The original SRTE P3Ta Pulley got a significant upgrade, now boasting a remarkable 120kN load capacity, up from the previous 80kN. This aluminium pulley will accommodate ropes 6 mm up to 24 mm diameter and has thicker side plates, giving an SWL of 800kg. Its reputation for durability earned over 30 years makes it a reliable choice for any tree or rigging job. The swing cheek design allows for effortless rope loading without threading from the end, ensuring proper connector alignment for safe operation. Crafted with a stainless steel axle and riveted for tamper-proof security, LRV8 have built this pulley to last. The self-lubricating sintered bronze bushing offers superior corrosion resistance and robustness compared to traditional ball bearings.

Minimum Qty

1 Items

Order Ships in

1 Bus Days


In Stock

Product Code: 209-14001001

All prices include GST
  • Super compact form factor with a versatile 6 mm - 24 mm rigging line capacity
  • Swing cheek release mechanism
  • Stainless steel axle running on self lubricating Oilite bronze bushings
  • 7 mm 7075 aluminum side plates
  • Impressive strength-to-weight ratio, with an 120kN MBS and SWL of 24kN
  • 50 mm sheave for improved bend ratio on the working line
  • Made by LRV8 Rescue in Sydney, Australia
Length 130 mm
Width 45 mm
Sideplates 7 mm
Weight 900 g
Suitable for cable? NO
Connector Hole Ø 22 mm
Working Line Ø 6 - 24 mm
MBS 120 kN
SWL 24 kN
